Product Description
The 1060 aluminum plate is a commercially pure aluminum alloy with an aluminum content of at least 99.6%. Belonging to the 1xxx series, it is known for excellent corrosion resistance, superior electrical and thermal conductivity, and outstanding formability.
Unlike heat-treatable alloys, 1060 aluminum gains its strength primarily through cold working and is available in various tempers such as O, H12, H14, H16, and H18. While its mechanical strength is relatively low, its exceptional ductility makes it ideal for deep drawing, spinning, and forming applications.
Typical uses include electrical conductors, chemical processing equipment, signage, lighting reflectors, heat sinks, and decorative panels.
1060 aluminum plate conforms to international standards such as ASTM B209, ISO 6361, and EN 573, ensuring consistent quality and dimensional accuracy for industrial, architectural, and decorative use.
| Item | Description |
|---|---|
| Alloy | 1060 (Al ≥ 99.6%) |
| Equivalent Names | Al99.6, A91060, EN AW-1060 |
| Temper | O, H12, H14, H16, H18, H22, H24 |
| Thickness | 0.15 mm – 6 mm (custom sizes available; thicker plates upon request) |
| Width | 600 mm – 2600 mm |
| Length | 400 mm – 16000 mm |
| Surface Finish | Mill Finish, Polished, Brushed, Anodized, Embossed, Sandblasted, Color Coated, PVC Coated |
| Standards | ASTM B209, ISO 6361, EN 573, GB/T 3880 |
| Payment Methods | T/T, L/C, Western Union |
| Packaging | Export-grade: wooden pallets + moisture-proof film + edge protection |
| Applications | Electrical conductors, chemical equipment, signage, lighting reflectors, heat sinks, decorative panels, kitchenware, building facades |
| Temper | Thickness (in) | Size (W × L, in) | Notes |
|---|---|---|---|
| O | 0.125 – 0.250 | 48 × 96, 48 × 120 | Mill finish, cut-to-size available |
| O | 0.250 – 0.500 | 48 × 120, 60 × 120 | Optional PVC film or anodizing |
| O | 0.500 – 1.000 | 48 × 144, 60 × 144 | For chemical and decorative use |
| O | 1.000 – 2.000 | 60 × 120, 60 × 144 | Heavy-duty industrial applications |
| O | 2.000 – 4.000 | 60 × 144, 72 × 144 | Excellent corrosion resistance |
| O | 4.000 – 6.000 | 72 × 144, 72 × 192 | Ideal for structural fabrication |
| O | 6.000 – 8.000 | 72 × 192, 96 × 192 | Custom large-format panels |
| O | 8.000 – 12.000 | 96 × 240 | Suitable for shipbuilding and machining |
| H112 | 0.250 – 1.500 | 60 × 120, 60 × 144 | Common for billboard & signage |
| H112 | 1.500 – 3.000 | 72 × 144, 72 × 192 | Used in heat sinks, industrial parts |
| H14 | 0.125 – 0.500 | 48 × 96, 48 × 120 | Higher strength, easy forming |
| H14 | 0.500 – 1.000 | 48 × 144, 60 × 144 | Decorative and structural use |
| H24 | 0.125 – 0.250 | 48 × 96, 48 × 144 | Balanced strength and ductility |
| H24 | 0.250 – 0.750 | 60 × 120, 60 × 144 | Ideal for exterior panels, chemical equipment |
1060 Aluminum Plate Tempers
Huashou steel provides 1060 aluminum plates in a complete range of tempers to suit various applications and performance requirements.
| Temper | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation A₅₀ (%) | Features |
|---|---|---|---|---|
| O | 60–95 | ≥35 | ≥12 | Excellent ductility and deep drawability |
| H12 | ≥80 | ≥35 | ≥12 | Moderate strength with good formability |
| H14 | ≥95 | ≥45 | ≥10 | Balanced strength and workability |
| H16 | ≥120 | ≥70 | ≥8 | Higher strength, good formability |
| H18 | ≥135 | ≥105 | ≥6 | Maximum strength, limited ductility |
| H22 | ≥80 | ≥35 | ≥12 | Partially annealed for toughness |
| H24 | ≥95 | ≥35 | ≥12 | Ideal balance of strength and ductility |
| H26 | ≥120 | ≥70 | ≥8 | High strength for heavy-duty use |
| H28 | ≥135 | ≥105 | ≥6 | Very high hardness, limited formability |
| H32 | ≥95 | ≥45 | ≥10 | Excellent corrosion resistance and strength |
| H38 | ≥135 | ≥105 | ≥6 | Maximum hardness and wear resistance |
| H111 | ~75–95 | ≥35 | ≥12 | Slightly strain-hardened, good corrosion resistance |
| H112 | ~75–95 | ≥35 | ≥12 | Great corrosion resistance for industrial use |
| Finish Type | Description |
|---|---|
| Bright | Smooth mill finish with high reflectivity |
| Polished | Mechanically polished for glossy appearance |
| Mirror | Ultra-reflective mirror-grade surface |
| Brushed | Linear texture, decorative look |
| Sand Blasted | Matte surface with fine texture |
| Anodized | Durable oxide layer with optional color finish |
| Embossed | Raised patterns for anti-slip or decorative use |
| Etched | Custom designs or logos via chemical etching |
| Color Coated | Painted in various colors for design flexibility |
| PVC Coated | Protective film prevents scratches during handling |
| Epoxy Coated | Durable epoxy paint for enhanced surface protection |
1060 aluminum is widely used across multiple industries due to its purity, conductivity, and corrosion resistance:
Architectural & Decorative – Curtain walls, ceilings, wall panels, embossed anti-slip sheets
⚡ Electrical & Thermal – Bus bars, transformer windings, capacitor casings, heat sinks
Packaging Industry – Food and chemical packaging, bottle caps, cosmetic containers
Kitchenware & Household – Cookware, utensils, lighting reflectors, furniture panels
Transportation & Industrial – Shipbuilding, machinery covers, signage, tanks
